Red Color Embedded solar road stud light IP68 Protect Die Casting Aluminum Shell

Red Color Embedded solar road stud light IP68 Protect Die Casting Aluminum Shell
Red Color Embedded solar road stud light IP68 Protect Die Casting Aluminum Shell Red Color Embedded solar road stud light IP68 Protect Die Casting Aluminum Shell Red Color Embedded solar road stud light IP68 Protect Die Casting Aluminum Shell Red Color Embedded solar road stud light IP68 Protect Die Casting Aluminum Shell Red Color Embedded solar road stud light IP68 Protect Die Casting Aluminum Shell Red Color Embedded solar road stud light IP68 Protect Die Casting Aluminum Shell

Large Image :  Red Color Embedded solar road stud light IP68 Protect Die Casting Aluminum Shell

Product Details:
Place of Origin: China
Brand Name: CADSOLAR
Certification: CE Approval
Model Number: CS-SR-816
Payment & Shipping Terms:
Minimum Order Quantity: 1PC
Price: USD14.00-16.00/PC
Packaging Details: 24pcs per carton,carton Size:38*27*28cm,22000pcs per 20" container
Delivery Time: 3-7days
Payment Terms: T/T, Western Union, L/C
Supply Ability: 100000PCS/Month

Red Color Embedded solar road stud light IP68 Protect Die Casting Aluminum Shell

Description
Name: Solar Underground Light Material: Aluminum
Color: Red Protect Level: IP68
Warranty: 2years Weight Resistance: 75 Tons
Solar Panel: 2.5V/200MA Monocystalline Solar Panel Battery: 1.2V/1200MAH Anti-high Temperature Ni-mh Battery
High Light:

Embedded solar road stud light

,

Aluminum Shell solar road stud light

,

IP68 solar studs for road

Aluminum underground solar road studs red color solar road stud



Quick Detail:



· Die-casting aluminum Shell

· Anti High-temperature

· IP68 protect

· CE approval

· 2 Years Warranty

· 50 tons weight resistance

· Good visible on foggy&rainy days

· Long lifespan

Red Color Embedded solar road stud light IP68 Protect Die Casting Aluminum Shell 0

Description:
Underground solar road stud are naturally charged by the sun. Once it starts to darken, the LED lights

turn on automatically every night. Underground solar road stud give special consideration to road

safety and can help prevent serious accidents and emit rather than reflect light. installed in the middle of road.



Specifications:

Model CS-SR-816
Solar Panel 2.5V/220MA mono-crystalline
Storage Components 1.2V/1200MAH High temperature NI-MH Battery
Lighting Time 100h after fully charged
Work mode Flashed for 120times per minute or Stable
LED Color Red,Yellow,Blue,Green,White
LED Qty 6PCS Diameter 10mm High Brightness LED
Visual Distance >1000meters
Life Span 3-5Years
Work Temperature -20℃~+80℃
Protect Level IP68,Can work under water
Material Anti-UV PC+silver coating Aluminum casing
Weight 900g
Weight Resistance in static >75 Tons
Products Size Diamter 120mm,Height 50mm
Package Carton size 38*27*28CM,24pcs per carton



Notices:

· 1. Open the packaging, check the products carefully, and take them gentely.

· 2. It should install it outside to get better sunshine

· 3. It should charge it and check it lighting before installation



Size Drawing:



Red Color Embedded solar road stud light IP68 Protect Die Casting Aluminum Shell 1



Packing:





Applications:



Red Color Embedded solar road stud light IP68 Protect Die Casting Aluminum Shell 2



Company information:



Shenzhen CadSolar Technology Co., Ltd, located in Shenzhen, is a hi-tech enterprise specialized in manufacturing solar& LED traffic products. With "Technology Innovation , Friendly Environment , Green Future” motto, Shenzhen CadSolar creates many solar LED traffic products step by step. After 6 years of efforts, most of our products are exported to Germany, France, Australia, New Zealand, Saudi Arabia, Dubai, Indonesia, Malaysia, Vietnam,South Africa, Kenya,Brasil, Chile etc...



Our Main Products as belowing:

Underground solar road studs

High-temperature resistance battery and circuit,can be used on the equator

● 15MM thickness PC cover and fully epoxy glue inside,weight resistance in static more than 742.7KN

Can install in the centre line of the road

Diam 5mm high brightness LED,Visual Distance more than 1000meters

Can double sides and 4 sides visible

Protect Level IP68

● Silver aluminum coating mounting case and nice design





Installation Procedure:

Close the road

• Check if the solar stud charges and discharges normally
• Identify the place for installation
Dig the hole for solar road studs
Inject the epoxy glue into the hole and place the solar road studs into the hole

Ensure the solar road studs and the ground in the same level.
• Wait 8 hours for glue drying before open the road





FAQ



Q1. Can I have a sample order for solar road studs?

A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.



Q2. What about the lead time?

A: 3-5 days for Sample preparing ,7-10 working days for mass production.



Q3. Do you have any MOQ limit for solar road studs order?

A: Low MOQ, 1pc for sample checking is available.



Q4. How do you ship the goods and how long does it take to arrive?

A: Ship by DHL, UPS, FedEx or TNT. It takes 3-5 days to arrive. Airline and sea shipping also optional.
